SPATIUM M390 NVMe M.2

Differences are marked in red SPATIUM M390 NVMe M.2 250GB SPATIUM M390 NVMe M.2 500GB
Model Name SPATIUM M390 NVMe M.2 SPATIUM M390 NVMe M.2
Capacity 250GB 500GB
Controller PHISON E15T PHISON E15T
Flash Memory 3D NAND 3D NAND
Form Factor M.2 2280 M.2 2280
Interface PCIe Gen3x4, NVMe 1.4 PCIe Gen3x4, NVMe 1.4
Compatibility PCIe Gen3 / Gen2 / Gen1 PCIe Gen3 / Gen2 / Gen1
Dimensions 80.00mm (L) x 22.00mm (W) x 2.15mm (H) 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s) 3300 3300
Sequential Write up to (MB/s) 1200 2300
Random Read 4KB up to (IOPS) 150,000 300,000
Random Write 4KB up to (IOPS) 300,000 550,000
Maximum Operating Power (W) 3.2 3.2
Idle Power PS3 (mW) 30 30
Low Power L1.2 (mW) 5 5
Operating Temperatures 0°C – 70°C 0°C – 70°C
Storage Temperatures -40°C – 85°C -40°C – 85°C
Terabytes Written (TBW) 150 200
Mean Time Between Failure (MTBF) Up to 1,500,000 Hours Up to 1,500,000 Hours
Limited Warranty 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. 5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
Advanced Features TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> End to End Data Path Protection <br /> APST (Autonomous Power State Transition) <br /> Pyrite (Encryption, Data Security) TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> End to End Data Path Protection <br /> APST (Autonomous Power State Transition) <br /> Pyrite (Encryption, Data Security)

使用している画像や特徴は一例です。撮影条件やモニターの設定などにより、商品の色と写真が多少異なる場合があります。
製品の仕様、機能、および外観は、GPUにより異なる場合があります。製品の詳細は最新の製品仕様ページをご参照ください。
仕向地や出荷時期により製品の仕様が異なる場合があります。また、予告なく仕様を変更することがあります。
実際の仕様につきましては、取扱販売店でご確認ください。
