Specifications for
MAG CORELIQUID 280R
Radiator Dimensions
Radiator Dimensions
312 x 140 x 27mm / 12.28 x 5.51 x 1.06 inches
Radiator Material
Radiator Material
Aluminum
Number of Fans
Number of Fans
2
Fan Dimensions
Fan Dimensions
140 x 140 x 25mm / 5.51 x 5.51 x 0.98 inches
Fan Air Flow
Fan Air Flow
84.36 CFM
Fan Bearing
Fan Bearing
Two Ball Bearing
Fan Rated Current
Fan Rated Current
0.19 A
Fan Speed
Fan Speed
500 ~ 1800 RPM
Fan Power Consumption
Fan Power Consumption
2.28 W
Fan Rated Voltage
Fan Rated Voltage
12V DC
Fan Noise Level
Fan Noise Level
14.8~33.28 dBA
Fan Lighting
Fan Lighting
ARGB
PWM Mode
PWM Mode
Yes
Fan Cable Length (5V ARGB / PWM cable)
Fan Cable Length (5V ARGB / PWM cable)
550 / 350mm; 21.65 / 13.78 inches
Block Dimensions
Block Dimensions
80.57x 66.82 x 48.58mm / 3.17 x 2.63 x 1.91 inches
Pump Speed
Pump Speed
4200±10%RPM
Pump Power Consumption
Pump Power Consumption
4.08W
Intel Socket
Intel Socket
LGA 1150/1151/1155/1156/1200
LGA 1366/2011/2011-3/2066
LGA 1366/2011/2011-3/2066
AMD Socket
AMD Socket
AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2
Accessories
Accessories
1 to 2 Fan PWM cable x 1
PSU Molex 4-Pin to 4-Pin(2 Pin Wired) Fan cable x 1
PSU Molex 4-Pin to 4-Pin(2 Pin Wired) Fan cable x 1
